Continuous deep fryer with paddles

This combination of the basic universal fryer and the paddle conveyor module is ideal for evenly frying thin, lightweight foods such as potato chips or extruded snacks. The blade-equipped conveyor can be easily mounted onto the tabletop universal fryer, enabling you to expand your product range with ease and efficiency.

With this module you can easily fry the following products:

• Customizable frying time – adjustable from just a few seconds to up to 50 minutes.
• Gentle handling – specially designed paddle shape ensures even the most delicate products remain undamaged.
• Uniform product distribution – а specialised separator at the inlet evenly spreads the product across the entire working area.
• Minimal product loss – the bottom conveyor prevents products from escaping the sidewalls or falling below the base conveyor level.
• Easy setup – simple installation and removal process for convenience.
• Enhanced safety – each heating element is equipped with safety thermostats.

This module features a stainless steel conveyor with four evenly spaced paddle sections along the entire length of the frying area. The high sidewalls allow products to float freely within the frying zone, while the blades gently submerge the products in oil, flip them over, and guide them toward the discharge conveyor (the unloading section of the lower base belt). The paddle movement and drive are fully synchronised with the base conveyor for smooth and efficient operation.

At the product inlet, a separator ensures that products do not stick together while evenly distributing them across the entire width of the conveyor. The paddles gently turn the product as they move it along the working length, providing constant and uniform agitation. This consistent stirring ensures even frying. The specially curved blade design minimizes the risk of damaging delicate or fragile products during the frying process.

Other additional modules for the fryer:

• Second upper pressure conveyor for forced immersion of the product in oil to achieve deep frying
• Work table for the fryer out of food grade stainless steel
• Oil reservoir with a capacity of 75 liters* The reservoir can only be ordered together with the worktable, as a part of it
• Automatic hot oil circulation system** with filtration, suitable for pre-treatment of products at the inlet of the fryer – a “waterfall” of hot oil to pre-fry the product, close the pores of the product and reduce its sticking

*Oil volume 75 liters +- 5 liters.

**For the version with a work table and an oil reservoir

• Working Area Length: 1 100 mm (43.3 inches)
• Working Area Width: 400 mm (15.7 inches)
• Oil volume: 60 l (15.85 gallons)
• Material: Stainless steel
• Principle of operation: Continuous mode
• Country of origin: Slovakia
• Total power: 12 kW
• Heating: Electricity
• Voltage: 380 – 400 V

Leaflets to download:

• SK: ELEKTRICKÁ DOPRAVNÍKOVÁ FRITÉZA MODULOVÁ 400/1100/12
• EN: MODULAR ELECTRIC COMPACT CONVEYOR FRYER 400/1100/12
• RU: УНИВЕРСАЛЬНАЯ МОДУЛЬНАЯ ФРИТЮРНИЦА 400/1100/12
